Custom Axis on Matplotlib Chart

logo of a chart:Cheat

This post describes several customisations you can apply on the axis of your matplotlib chart. These examples are applied on the X axis but they can naturally be imitated for the Y axis!

Axis Titles

You can customize the title of your matplotlib chart with the xlabel() and ylabel() functions. You need to pass a string for the label text to the function. In the example below, the following text properties are provided to the function in order to customize the label text: fontweight, color, fontsize, and horizontalalignment.

# Libraries
import numpy as np
import matplotlib.pyplot as plt

# Data set
height = [3, 12, 5, 18, 45]
bars = ('A', 'B', 'C', 'D', 'E')
y_pos = np.arange(len(bars))

# Basic bar plot
plt.bar(y_pos, height, color=(0.2, 0.4, 0.6, 0.6))

# Custom Axis title
plt.xlabel('title of the xlabel', fontweight='bold', color = 'orange', fontsize='17', horizontalalignment='center')

# Show the graph
plt.show()

Ticks

The tick_params() function of matplotlib makes it possible to customize x and y axis ticks. The parameters are:

  • axis : axis to apply the parameters to (possible options are: 'x', 'y', 'both')
  • colors : tick and label colors
  • direction : puts ticks inside the axes, outside the axes, or both (possible options are: 'in', 'out', 'inout')
  • length : tick length in points
  • width : tick width in points
  • bottom : whether to draw the respective ticks (True or False)
# Libraries
import numpy as np
import matplotlib.pyplot as plt

# Data set
height = [3, 12, 5, 18, 45]
bars = ('A', 'B', 'C', 'D', 'E')
y_pos = np.arange(len(bars))

# Basic plot
plt.bar(y_pos, height, color=(0.2, 0.4, 0.6, 0.6))

# Custom ticks
plt.tick_params(axis='x', colors='red', direction='out', length=13, width=3)

#Show the graph
plt.show()

# You can remove them:
plt.bar(y_pos, height, color=(0.2, 0.4, 0.6, 0.6))
plt.tick_params(bottom=False)
plt.show()

Labels

You can customize axis tick labels with the xticks() and yticks() functions. You should provide the positions at which ticks should be placed and a list of labels to place.

# Libraries
import numpy as np
import matplotlib.pyplot as plt

# Data set
height = [3, 12, 5, 18, 45]
bars = ('A', 'B', 'C', 'D', 'E')
y_pos = np.arange(len(bars))

# Basic plot
plt.bar(y_pos, height, color=(0.2, 0.4, 0.6, 0.6))

# use the plt.xticks function to custom labels
plt.xticks(y_pos, bars, color='orange', rotation=45, fontweight='bold', fontsize='17', horizontalalignment='right')
plt.show()

# remove labels
plt.bar(y_pos, height, color=(0.2, 0.4, 0.6, 0.6))
plt.tick_params(labelbottom=False)
plt.show()

Limits

It is possible to set the limits of the x axis using the xlim() function.

# Libraries
import numpy as np
import matplotlib.pyplot as plt

# Data set
height = [3, 12, 5, 18, 45]
bars = ('A', 'B', 'C', 'D', 'E')
y_pos = np.arange(len(bars))

# Basic plot
plt.bar(y_pos, height, color=(0.2, 0.4, 0.6, 0.6))

# Set the limit
plt.xlim(0,20)

# Show the graph
plt.show()
Animation with python

Animation
